The compact class.
The first in its class with APS. The APS threshing and separation system already performs beautifully in the LEXION and the TUCANO. This proven threshing technology from CLAAS is also available in the compact class.
How you benefit.
- Up to 20% more throughput with APS without any increase in fuel consumption
- Large, soundproofed cab for a quiet environment which allows you to focus on your work
- Visual returns checked from the operator's seat through the illuminated inspection window
- Versatile multifunction control lever and CLAAS Information System (CIS) for optimal interaction between operator and machine
- VARIO cutterbars improve performance by up to 10% due to even crop flow
- CORIO and the folding cutterbar or the MAXFLEX cutterbar provide versatile harvesting solutions
- Comfort cab
- Intensive separation system
- Perkins engine
- PROFI CAM
- Straw chopper
- 3D-cleaning system
- High-performance straw walker
- Rotary fan
- APS (AVERO 240)
- Hydrostatic reel drive
- Folding dividers
- VARIO table
- MultiCoupler
- CIS
| Threshing system / width | mm |
| Grain tank | l |
| Maximum engine power (ECE R 120) | kW/hp |
| AVERO 240 | |
| Threshing system / width | APS / 1060 |
| Grain tank | 5600 |
| Engine Stage IV (Tier 4) | Perkins 1206 F-E70TA |
| Engine Stage IIIa (Tier 3) | Perkins 1106 D-E70TA |
| Maximum engine power (ECE R 120) | 151/205 |
| AVERO 160 | |
| Threshing system / width | Conventional/1060 |
| Grain tank | 4200 |
| Engine Stage IV (Tier 4) | Perkins 1206 F-E70TA |
| Engine Stage IIIa (Tier 3) | Perkins 1106 D-E70TA |
| Maximum engine power (ECE R 120) | 116/158 |
| Threshing system / width | Grain tank | Engine Stage IV (Tier 4) | Engine Stage IIIa (Tier 3) | Maximum engine power (ECE R 120) | |
| mm | l | kW/hp | |||
| AVERO 240 | APS / 1060 | 5600 | Perkins 1206 F-E70TA | Perkins 1106 D-E70TA | 151/205 |
| AVERO 160 | Conventional/1060 | 4200 | Perkins 1206 F-E70TA | Perkins 1106 D-E70TA | 116/158 |
AVERO 240 with APS threshing system.
- Greatly improved acceleration of the crop flow
- Higher centrifugal forces
- Separation of up to 30% of the grain in the pre-cleaning concave
CLAAS threshing system.
The AVERO 160 is equipped with the classic CLAAS threshing unit. Clean threshing, protective grain handling, optimal deawning and high separation efficiency deliver best grain quality.
CLAAS INFORMATION SYSTEM (CIS).
The compact CIS terminal is ergonomically integrated in the operating panel and gives the operator a quick overview of important information for the combine.
Active fluffing.
The AVERO 160 is equipped with the classic CLAAS threshing unit. Clean threshing, protective grain handling, optimal deawning and high separation efficiency deliver best grain quality.
Cab + Comfort
Spacious cab.
It was a long working day, but it didn't feel like one. When this is what crosses your mind as you park your AVERO for the night, our engineers have achieved their goal.
They have created a cab that is so comfortable and ergonomic that the operator can focus entirely on his or her work. Attractive design, plenty of space, good visibility on all sides and easy-to-operate instruments make a day harvesting in the AVERO as stress-free as it gets.
Spacious, exceptionally quiet cab:
- A well-organised operating panel with superior ergonomics
- Steering column with three-way adjustment
- A comfortable passenger seat
- A/C MATIC automatic climate control
- In-cab master terminal compartment
- Illuminated inspection window for monitoring returns
- Threshing concave controls
The AVERO also offers the same easy, convenient operation as the LEXION and the TUCANO. For example, the cutterbar, threshing unit and grain tank offloading are activated via electrohydraulic circuits.
Powerful lighting.
The lighting in the AVERO ensures excellent visibility during the twilight hours and in the dark. Up to eight work lights ensure optimal lighting of your immediate work environment. In addition to the legally required lighting for on-road use, the AVERO can also be equipped with extra lighting for folding front attachments.
Furthermore, the following functional areas are equipped with spotlights to ensure the best visibility night and day:
- Returns check
- Grain tank
- Grain tank unloading tube
- Sieve pans
Electrically adjustable rear-view mirrors as well as front and side roller blinds for an optimal view.
Intelligent harvest aids at work.
The productivity of a harvest job is determined by how well an operator controls the combine. With its ergonomically shaped multifunction lever, the AVERO offers outstanding driving comfort and ease of operation.
The multifunction lever is used to regulate ground speed and control many other functions conveniently:
- Direction of travel
- Cutterbar and reel settings
- Cutterbar brake
- Grain tank offloading ON / OFF
- Pivoting the grain tank unloading tube
Well-organised information terminal.
The compact CIS terminal is ergonomically integrated in the operating panel and gives the operator a quick overview of a wide variety of important machine data. Thus the interaction between the operator and the machine can be continuously optimised during a job.
PROFI CAM – everything in view.
All AVERO models can be equipped with a PROFI CAM on the rear hood. This camera position has been chosen precisely to allow two areas to be monitored simultaneously on a colour display from the comfort of the cab:
Distribution of chopped material / straw deposition
Rear of machine when reversing
Up to four cameras can be connected to the system and simultaneously feed their images to the colour monitor in the cab.
Unique APS threshing system.
The AVERO 240 is the first in its class with APS. The distinct competitive edge of this trend-setting threshing system appears well before the threshing drum as the dramatic acceleration of the crop flow from 3 m/s to 20 m/s triggers a chain of extremely efficient processes:
- The pre-accelerator separates the crop more thoroughly
- The crop flow is particularly even and up to 33% faster
- Higher centrifugal forces sort considerably more grains
- Up to 30% of all grains are already sorted in the pre-separation concave directly below the accelerator, significantly reducing the load on the main concave
Thus there is a net performance increase of up to 20% with no rise in fuel consumption. APS really pays.
Versatile pre-separation concave.
The pre-separation concave is designed as a MULTICROP concave and can therefore handle any crop. The option of quickly changing two concave sieves minimises setup time and maximises efficiency.
Long threshing channel.
In the CLAAS APS threshing system, we have succeeded in wrapping the main concave much farther around the threshing drum than in conventional machines. No other threshing unit offers an angle of wrap of 151°. You benefit from gentle but thorough threshing with a large concave clearance and low drum speed with reduced fuel consumption.
Improved grain quality.
For optimal deawning and decortication, the APS threshing system is equipped with multi-level adjustment options and additional components. These include, for example, the intensive threshing unit and the deawning plates. The deawning plates are activated in mere seconds with a lever above the feeder housing.
Together with the other APS benefits, the result is impressive: optimal separation efficiency combined with outstanding harvest quality.
The champion in all fields.
The AVERO 160 uses the classic CLAAS threshing unit which consistently provides impressive proof of its ability to handle the two key threshing tasks of removing and separating grains reliably in all harvest conditions. Regardless of the harvesting challenges you face, you'll be impressed by the versatile performance it delivers across the full threshing drum width of 1.06 m.
- The threshing unit can be easily accessed from the front via the feed rake and from both sides through large openings
- The extremely robust design of all the drives, and of the threshing drum drive in particular, ensures top reliability during the harvest
Fit for any crop. The MULTICROP concave.
The concave below the threshing drum is designed as a MULTICROP concave with individual segments that can be changed easily. You can switch the concave quickly for a wide assortment of crops – always ensuring the right combination of clean threshing, protective handling of the crop and a high separation rate.
The AVERO 160 is equipped with the classic CLAAS threshing unit.
Unique APS threshing system.
The APS threshing system works so efficiently that the residual grain separation system in the AVERO 240 requires fewer straw walkers than you'd expect. Thanks to APS, 90% of the grain is already separated from the straw. Four straw walkers with four steps take care of the remaining 10%.
The AVERO 240 processes as much as a comparable machine with five straw walkers without APS, but has the compact dimensions of a machine with four straw walkers. This has a noticeable economic impact. The AVERO 160 also delivers above-average performance for its size: the classic CLAAS threshing unit works perfectly in combination with the four straw walkers.
Four straw walker steps.
In addition, the straw undergoes intensive separation with controlled agitator tines. Agitator tines located above each straw walker dig deep into the straw, loosening and fluffing it to ensure a rapid straw flow and a thin layer of straw for the last grains to escape and effectively increase separation efficiency.
Active fluffing
AVERO provides you with numerous monitoring aids for optimal utilisation of the installed features of the machine and to achieve the best possible threshing quality:
- Throughput monitor for the residual grain separation system and cleaning in the CIS
- Yield recording and fuel consumption measurement with CIS
- Returns fed back to threshing unit
- Illuminated inspection window for monitoring returns
- Crop monitoring in the grain tank via a large inspection window
Complete control
AVERO provides you with numerous monitoring aids for optimal utilisation of the installed features of the machine and to achieve the best possible threshing quality:
- Throughput monitor for the residual grain separation system and cleaning in the CIS
- Yield recording and fuel consumption measurement with CIS
- Returns fed back to threshing unit
- Illuminated inspection window for monitoring returns
- Crop monitoring in the grain tank via a large inspection window
A look into the grain tank: clean work.
Large grain tank.
Once the threshing unit, straw walker and cleaning section have done their work, the cleaned grain is collected in the grain tank. A particularly impressive feature of the AVERO is its capacity of up to 5600 litres. However, this is but one of its many strengths.
- Easy grain sampling
- High overhead discharge height
- Ideal weight distribution
- Good view into grain tank
- Grain tank cover can be operated from operator's platform
- Fast, direct offloading
- Smooth surfaces for fast, complete emptying
Powerfull fan
The AVERO has a rotary fan for the best grain cleaning. Its speed can be controlled from the cab, providing constant air pressure and even distribution of air across the sieves to handle varying crop loads. Forced air guidance prevents the formation of crop mats.
In addition, the AVERO is equipped with the impressive features of the 3D-cleaning system developed by CLAAS:
- Dynamic side slope levelling via active control of the upper sieve
- Completely consistent performance on side slopes up to 20%
- No wear - completely maintenance free
- Fast, simple retrofitting
Removable preparation floor
Pre-sorting of the grains (bottom) and the chaff and broken straw (top) takes place on the preparation floor. The resulting reduction of the load on the upper sieve increases cleaning capacity. The preparation floor can be removed easily for cleaning when the harvest is completed.
Direct view.
Sometimes a glance into the grain tank can tell you more than any number of sensors. A large inspection window in the back of the AVERO cab enables visual yield monitoring, so the returns can be viewed conveniently from the operator's seat. The inspection window is illuminated for better visibility.
Straw management. From small and short to long and loose.
Short chopped material.
The AVERO distributes the uniformly short-chopped straw over the entire cutterbar width and blows it deep into the stubble. The discharge width is easily adjustable.
The CLAAS choppers are also equipped with a shear bar. Both components can be individually adjusted and thus adapted to the varying straw conditions. This ensures that no stalk is left uncut. Chopping takes place using rotating knives and a stationary cutting comb.
Top-quality straw.
The AVERO handles long straw very gently. Thanks to the protective threshing and separation process, the straw retains its full original structure, which is ideal for high-quality bedding straw. When the straw chopper is switched off, the swath is layered loosely, allowing it to dry quickly and be baled easily.
PROFI CAM – everything in view.
All AVERO models can be equipped with a PROFI CAM on the rear hood. This camera position has been chosen precisely to allow two areas to be monitored simultaneously on a colour display from the comfort of the cab:
- Distribution of chopped material / straw deposition
- Rear of machine when reversing
Up to four cameras can be connected to the system and simultaneously feed their images to the colour monitor in the cab.
AVERO 240. Tough enough to cope with rice.
Takes rice in its stride: the APS threshing unit.
As rice grains are delicate, a spike-toothed threshing drum is used instead of the usual rasp bar threshing drum. The spike teeth on the threshing drum rub the rice grains out of the plant's panicles. The spike teeth are offset on the bars of the threshing drum and pass between the stationary spike teeth on the threshing concave.
Additional toothed bars are bolted to the impeller to direct the heavy rice straw onto the straw walkers reliably under all conditions.
The chassis of the AVERO 240.
The more difficult harvesting conditions in rice fields make great demands on the machine. Specially sealed axles are available for use in very wet conditions. These ensure reliability and durability, under even the most adverse conditions.
Grain tank HD.
Rice grains are particularly aggressive and cause a high degree of wear during grain collection and grain tank unloading. This is why there is a particularly wear-resistant version of the grain tank, in which the augers for filling and unloading the grain tank as well as the auger in the grain tank unloading tube have a special coating.
C490 and C430 standard cutterbars for rice harvesting.
The intake auger of these cutterbars is also available as an HD version whose auger thread is specially coated to reduce wear by plants and dirt adhesion. These cutterbars can be equipped with two different cutting systems to ensure that the crop is cut cleanly:
Special double fingers and crop guards for the knife bar (crop lifters can be used)
Twin knife system (crop lifters cannot be used)
Rice harvesting with VARIO and CERIO cutterbars.
The VARIO and CERIO cutterbars are also available with special equipment for rice harvesting. As in the case of the C490 and C430 cutterbars, the intake auger is coated to reduce any wear as much as possible. Here, too, a special cutting system is available for trouble-free cutting of the rice plants. The short double fingers and the optimised crop guards ensure a precise cut and blockage-free operation.
Engine. Using brawn and brains to get the job done.
Top performance.
The rugged PERKINS engine offers plenty of reserve capacity and powers the AVERO through long, productive work sessions even under tough field conditions. State-of-the-art technology keeps diesel consumption remarkably low.
The AVERO complies with the Stage IV (Tier 4) emissions standard thanks to SCR (selective catalytic reduction) in combination with EGR (exhaust gas recirculation) and a diesel particulate filter. The urea solution required for the SCR reaction is carried in a 30-litre tank. No additional exhaust aftertreatment equipment is required for compliance with the Stage IIIA (Tier 3) emissions standard.
The new generation of Perkins engines with outputs of 116 kW / 158 hp (AVERO 160) and 151 kW / 205 hp (AVERO 240) allows the machines to be operated productively for extended periods, even under difficult field conditions.
Optimised combustion process
Improved engine running characteristics
Low fuel consumption
Optimal power transmission
Up to 400 l fuel tank capacity
Intelligent ground drive.
No engaging and disengaging the clutch, no shifting gears - just full concentration on the harvest. You control the innovative, hydrostatic ground drive of the AVERO conveniently and comfortably with the multifunction lever.
Such operating comfort enhances performance. You can turn faster and adapt the ground speed immediately to the changing field conditions. The high pump volume ensures responsive handling under all conditions.
Engine. Using brawn and brains to get the job done.
Easy maintenance.
- Pivoting radiator frame for fast manual cleaning
- Large, continuous side panels for unimpeded access
- Easy access to the engine compartment and other maintenance areas with a mobile, foldable ladder
- Rear hood opens if necessary
- Long service intervals
- Lubrication banks
- Storage box for tools
Fast access.
Maintenance is very simple, requiring little effort or time, while the service intervals for the AVERO are long. All important maintenance points are easily accessible, and the best part is that much of the work can be done quickly by the operator.
New: intelligent cooling system with automatic dust extraction.
The AVERO works with an extremely efficient common cooling system for the engine, hydraulics and climate control system. Automatic dust extraction continuously cleans the hydraulically rotating radiator frame and provides optimal cooling while it significantly reduces soiling of the cooling ribs. The radiator frame can be pivoted for better cleaning.
